CL-112 RFID Metal Zinc Alloy Digital Password Drawer Cabinet Lock

CL-112 RFID Metal Zinc Alloy Digital Password Drawer Cabinet Lock

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

The CL-112 Electric Cabinet Lock is designed to electronically secure cabinets and drawers. The addition of a keypad or remote control of your choice provides true access control and convenience of use.
Application Fields: Gym, Spa, Health and Fitness clubs, Golf, Swimming Pool, Sauna, Athletic locker rooms, Schools, Colleges and Universities, Hotels, and Office.
Outer shell is made of extra good quality metal material, which is painted by powder-spray craft work.
This lock is special designed, with every aspect of environment and operation impacts the experience your facility provides.
Multiple lock body & management solutions, interface, function and latch options to match your facility’s application.
Fault Tolerant Input function, any incorrect digits code can be input before inputting the correct code
Free Choice Function available for pubic storage solution application.
Different Color is available with Black, Shinning-silver, Black, Golden, Color Is Optional.
OEM/ODM available, Customer’s logo printed available.
 Model  CL-112
 Material  Lock Panel: Zinc alloy; Lock body: ABS
 Password digit  ≥4, ≤ 10
 Power source  DC6V alkaline battery( AA1.5V*4pcs)
 Static current  <10uA
 Dynamic current  <220mA
 Alarm power  < 4.7V; alarm by red light
 Size  58*34.8mm
 Memory capacity  4160 Bit
 Work temperature  -15℃~65℃
 Work humidity  5%~95%RH(No condensation)
 Anti-static electricity  Air discharge 15KV,Contact discharge 8KV
 Battery life  >10,000 times
 Suitable for door thickness  All
 Double mode  Public mode or private mode; It can be changed as your need.
 Jump Code  Another way for emergency opening
