Product

Electric Strike for Push Bar(EL-622-S)

Enhanced stress structure design. The special design of this lock is applied to all different brands of fire push rod lock. It is passed the 1,000,000 Mechanical test. You can set the operation mode of Fail Safe or Fail Secure.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Enhanced stress structure design

1000000 solenoid valve special design

Power to open the door or door adjustable power supply

12/24VDC/VA
N/A
Product Parameter Parameter Description
Lock Size  153.5Lx43Wx49H(mm)
lock tongue structure  304 Stainless Steel
Holding Force  1000kg
Voltage  DC12V
Current  12V/320mA;24V/160mA
Signal Output  Door sensor NO/NC/COM
special design  applies to all brands of fire push rod lock
Suitable For  European & American fire push bar
Surface Temperature  Within +20℃
Suitable Temperature  -10~+55℃(14-131F)
Operating Humidity  0～90%(non-condensing)
Face plate Housing  High temperature paint
Lock tongue  Surface by coating nickel
The door open 90 degrees
Weight  0.52kg
